PIR Air Duct Panel with Smooth Aluminum Foil
Thickness : 20mm / 25mm / 30mm
Facing : 80micron embossed / smooth
Facing material : silver / silver aluminum foil
Density : 40-50 kg/m3
Size : 3.95/2.95 m×1.2 m, 10 sheets packed by plastic film
Email Address:[email protected]
PIR Air Duct Panel with Smooth Aluminum Foil
PIR Air Duct Panel consist of Polyisocyanurate (PIR) insulation Foam and both sides with 80micron embossed and smooth aluminum foil. PIR panel with smooth surface has antibacterial performance, making it a prevalent choice for applications in clean room projects, such as Hospital, Food factory, and other fields that require a highly clean environment. These all can use PIR Duct system. PIR Insulation Board is also fireproof and environmental protection.
Technical Data Sheet
|
Foam Density |
kg/m3 |
40-50 |
|
Aluminum Foil Thickness |
micron |
80 |
|
Thermal Conductivity |
W/m.K |
0.02 |
|
Fire Rating |
|
BS 476 Part 6 & 7 Class 0 |
|
Compressive Strength |
Mpa |
0.25 |
|
Bending Strength |
Mpa |
2 |
|
Water Absorption |
% |
0.1 |
|
Dimension Change |
% |
0.3 |
|
Maximum Wind Velocity |
m/s |
13-20 |
|
Maximum Running Temperature |
℃ |
80 |
Application and Advantage of PIR Air Duct Panel
GFI PIR Pre-insulated Duct Panel with smooth aluminum foil, a premium solution engineered for cleanliness-sensitive environments such as hospital and food processing factories. PID Duct Panel faced with a smooth aluminum foil that not only has antibacterial function but also facilitates easy cleaning, crucial for maintaining hygiene standards.
Our PIR Panel is designed to meet the rigorous demands of clean room applications, ensuring optimal air quality and contamination control. With their exceptional thermal insulation properties and durable construction, they provide reliable performance while minimizing energy consumption. Elevate your clean room infrastructure with our PIR Duct Panel, delivering unparalleled efficiency and hygiene in critical environments.
Why Choose GFI PIR Air Duct Panel ?
01 / GFI PID Duct Panel has a low thermal conductivity and good thermal performance. The thermal conductivity of GFI Pre-insulated Duct Panel is about 0.018-0.022W/(m·k), which is the lowest among all insulation materials.
02 / GFI Polyurethane HVAC Duct Panels is fire-resistant and high-quality insulation materials. GFI PIR Duct Panel will form a layer of char on its foam surface when burning, which helps isolate the foam underneath. This char layer effectively prevents flame spread, and does not produce harmful gases when burning.
03 / GFI PIR Insulation Board have moisture resistance, waterproofing, and antimicrobial properties.
04 / PID Duct Panel have many advantages over regular metal ductwork, such as lighter weight, higher strength, longer durability, and better efficiency.
05 / GFI factory can produce different facing materials to meet different requirements and applications. It is widely used in various ventilation systems of central air conditioning units.
Fabrication of GFI PIR Pre-insulated Duct Panels
The construction of GFI HVAC Duct is accomplished by following a standard procedure by Pre-insulated Duct Tool Box or CNC cutting machine. The process is the same regardless of the shape of the duct element: tracing, cutting, gluing, folding, taping, flanging & reinforcement and sealing.
Packing and Shipping
The length and packaging of GFI PIR Duct Panel can be customized. Usually it will be cut and packed as below details:
01 / 40’HQ Container: 3950/2950*1200*20mm, 10 sheets packed in one carton, total 660sheets(3950mm) / 880sheets(2950mm).
02 / 20’GP Container: 2900*1200*20mm, 10 sheets packed in one carton, total 400sheets.
